Troubleshooting

Record the repository revision, project, selected agent, failing command, and exact error before changing anything. Work in the same environment that failed. Redact credentials and sensitive configuration from shared evidence.

Agent names

Use the current names in the agent picker rather than historical codenames. The workflow roster lists main agents. 01-Orchestrator helps identify the next step; the owner selects it.

Quick decision tree

Failure	Start here
Missing agent or skill	Verify the checkout, file, invocation flags, and editor diagnostics.
Corrupt or conflicting state	Use session state debugging.
Authentication	Test the specific tool’s context without printing tokens.
Policy or preview	Preserve the failing evidence and return to the responsible step.
Site build	Use apex-docs commands, not product validators.

Common issues

1. Agent not appearing in list

Confirm that you opened the product or Accelerator repository, not this site-only checkout. Check .github/agents/ and the relevant file’s frontmatter. Confirm Copilot access and inspect editor diagnostics. Reload the window after a corrected configuration if needed.

2. Orchestrator does not invoke the next main agent

This is expected in the current workflow. Main agents, including Challenger, require human selection. Do not add wildcard agents: ["*"] permissions or an obsolete experimental setting to make Orchestrator delegate.

If an allowed helper fails, inspect the parent agent’s actual tool and helper declarations. Main-agent handoffs and bounded helper calls are different mechanisms.

3. Skill not activating automatically

Read its SKILL.md invocation flags. Manual-only skills require explicit selection. Name the skill and requested task, or load its instructions explicitly when the client cannot discover it. Do not claim that keyword matching proves a skill loaded.

4. Deployment fails with Azure policy error

Capture the assignment/definition, target scope, evaluated property, and exact failure. Return stale or incomplete policy discovery to Governance. Return design, plan, or code conflicts to their owners.

Do not choose a new SKU, remove a tag, or enable public access merely to pass a deployment. Effective policy and the approved design determine the correction.

5. Bicep build errors

From the product root, replace {project} with the actual project:

bicep --version
bicep restore infra/bicep/{project}/main.bicep
bicep lint infra/bicep/{project}/main.bicep
bicep build infra/bicep/{project}/main.bicep

Check registry access, module versions, parameters, and the reported source location. Return repairs to Bicep CodeGen and renew the handoff after changes.

5T. Terraform validation errors

Check the project’s provider constraints and lock file before changing versions. For configuration-only validation in the project directory:

terraform version
terraform init -backend=false
terraform fmt -check -recursive
terraform validate

This does not establish remote-backend readiness or authorize a plan/apply. Do not force-unlock state as a routine fix. Confirm no operation owns the lock and obtain explicit authorization for a state-changing recovery action.

6. Azure authentication issues

Azure CLI (`az`)

An account listing does not validate a token. Check both context and token acquisition:

az account show --output table
az account get-access-token --resource https://management.azure.com/ --output none

If authentication expired, sign in with the intended identity and recheck the subscription. Do not change identities merely to bypass a permission failure.

Azure developer CLI (`azd`)

Azure CLI and azd have separate caches. Check azd with:

azd auth login --check-status

Use the organization’s approved sign-in method if it needs reauthentication.

Service principal authentication

Verify tenant, application identity, and assigned scope without exposing secrets. Use the organization’s approved automation identity and credential mechanism. Do not paste credentials into prompts, committed scripts, or diagnostic bundles.

7. Artifact validation failures

Compare the affected artifact with its current template under .github/skills/apex-azure-artifacts/templates/. Preserve required headings and their order. Run the check named in the failure through the supported product workflow. Do not delete mandatory sections to satisfy a prose cleanup.

8. MCP server not responding

Check .mcp.json, the client’s registered servers, authentication, and the specific tool’s error. Restart the failed server through the client’s MCP controls when appropriate.

Missing pricing evidence must remain missing. Work that does not depend on the failed tool may continue, but a required check cannot become a success by fallback. Governance uses Azure authentication independently of retail-pricing access.

9. Dev container build fails

Read the first failed build step. Confirm Docker is available and WSL integration is enabled. Check proxy, registry, disk, and port errors before rebuilding. Do not disable TLS verification to get past a package-download failure.

If setup fails at an npm or Python install, check the package sources line in the startup output and see package sources. If a customized container stopped building after an update, see the migration steps.

Use container setup for the supported environment. A successful native Windows dev preview does not establish Linux build compatibility.

10. Unexpected extension instructions

Inspect the active remote and local extension lists and the conversation’s context diagnostics. Compare them with the actual container configuration. Product and template revisions can differ.

Disable or uninstall a confirmed unwanted extension through VS Code, then reload. Do not recursively remove extension directories based on an unverified name match. If it returns, inspect image/configuration sources before rebuilding.

11. Git push fails with Lefthook errors

Identify whether the failure comes from pre-commit, commit-message, pre-push, or CI. Run the named check from the correct repository root and fix its cause. Product scripts do not necessarily exist in apex-docs.

Do not use --no-verify as a routine workaround. A corrected commit message does not resolve a failing source or artifact validator.

12. Handoff prompt not working

Check that the target agent exists and matches the handoff declaration. Main-agent selection remains a human action. Inspect malformed frontmatter or a client discovery problem rather than adding delegation privileges.

Diagnostic commands

Environment check

Run only the checks relevant to the failure:

node --version
python3 --version
git --version
bicep --version
terraform version
az version

Workspace validation

Read the current repository’s package.json and CI workflow. The validation reference separates product and site checks. Run infrastructure checks in their actual project directory.

Azure status

These commands read the selected subscription and specified resource group:

az account show --output table
az deployment group list --resource-group "{resource-group}" --output table

Redact output before sharing it. A deployment record alone is not evidence that application endpoints are healthy.

Getting help

Provide a reproducible failure, source revision, selected agent, and redacted logs. Use the product issue tracker for APEX behavior and the docs tracker for site problems.

Still stuck?

Select 09-Diagnose for deployed-resource investigation or 01-Orchestrator to identify the owning workflow step. State whether the request is read-only. Diagnosis does not authorize remediation.
